Get known of Outdoor 4G Router on the technical specification, electrical parameter, working frequency, upload speed, download speed, wireless network speed, advanced chipset, powerful Wi-Fi booster, IP67 rated hardware, high-gain FRP antenna, and even more.

2G/3G/4G Cellular Modem

The Outdoor Router supports a variety of mobile networks, including 2G 3G and 4G. The different cellular networks use different standards and different frequencies. With years research and developing experiences, we deploy the most used network standards and frequencies for the different versions of the Outdoor Routers. Some of the minority mobile carriers might not be able to support, please contact our sales team if you need help to verify the working ability.

European & UK Standard
Mobile Frequencies

4G FDD-LTE Band 1: 2100MHz
4G FDD-LTE Band 3: 1800MHz
4G FDD-LTE Band 7: 2600MHz
4G FDD-LTE Band 8: 900MHz
4G FDD-LTE Band 20: 800MHz
4G TDD-LTE Band 40: 2300MHz

3G WCDMA: 2100/900MHz
3G TD-SCDMA: B34/B39

2G GSM/GPRS/EDGE: 900/1800MHz

American & Canadian Standard
Mobile Frequencies

4G FDD-LTE Band 2: 1900MHz
4G FDD-LTE Band 4: 1700MHz
4G FDD-LTE Band 5: 800MHz
4G FDD-LTE Band 8: 900MHz
4G FDD-LTE Band 17: 700MHz
4G FDD-LTE Band 18: 800MHz

3G WCDMA/HSPA+/DC-HSPA+
3G B1: 2100MHz / 3G B5: 850MHz

2G GSM/GPRS/EDGE: 850/1900MHz

Cellular Transmission Rate

4G FDD-LTE: UL 50Mbps DL 150Mbps
4G TDD-LTE: UL 50Mbps DL 150Mbps
3G HSPA+: UL 5.76Mbps DL 21Mbps
3G TD-SCDMA: UL 2.2Mbps DL 2.8Mbps

Wi-Fi Router

Wi-Fi standards: 802.11b/g/n
Wi-Fi channel: 13
Wi-Fi encrytion: Open/WPA-PSK/WPA2-PSK
Frequency: 2412MHz-2472MHz

Simultaneous connections: 1~32 Users
Wi-Fi transmission rate: 150Mbps
Output power: Adjustable 20/27/30dBm
Data management: By data or by time

Power consomption: < 2.5 Watt
Supports Wi-Fi hotspot relay function
Hide SSID available

Hardwares

Antenna: 5/6dBi FRP antennas
USIM/SIM: Nano SIM card
Ports: 2 x 10/100 RJ45 ports
Indicators: 2G/3G/4G/Wi-Fi
PoE injector: DC24V-1A / AC120-250V

Waterproof: IP67
Working temperature: -30 to 80°C
Working humidity: 10%-90% RH
Storage temperature: -40 to 85°C

Installation: Pole mounted
Measurement: 160x110x60mm

Operation System

Support system: Built-in Firmware
Data modulation: OFDM
Computer supported:
Windows XP Vista 7 8/8.1 MAC OS X 10.7+

Package Contents

1 x Outdoor Router
2 x FRP Aerial
1 x 10-Meter LAN Cable
1 x 3-Meter LAN Cable
1 x 15V PoE Injector
1 x Mounting set & tool
1 x SIM Card Adapter

Outdoor 4G Router WiFi Booster V3

Outdoor Router

European Version
American Version
UK Version
Accessory

Outdoor Long-range 4G LTE Router

Need Wi-Fi Hotspot in Remote Areas?
Need Internet Service for Outdoor Events?

It's time to deploy a 4G Outdoor WiFi Router in the countryside, coast, yacht, caravan, campus, campsite, remote area, outdoor concert, and sports event!

Free Shipping 30-Day Money Back 1-Year Warranty
Outdoor Router Application in CountrySide Rural Area
Outdoor Router Application in Coast Beach
Outdoor Router Application in Caravan
Outdoor Router Application in Outdoor Campsite
Outdoor Router Application in Outdoor Concert
Outdoor Router Application in Outdoor Golf Ground
